0.6/1kV AL/XLPE/STA/PVC Cable

0.6/1kV AL/XLPE/STA/PVC Cable

The 0.6/1kV AL/XLPE/STA/PVC cable is a reliable low-voltage power cable designed for efficient electricity distribution in industrial, commercial, and residential applications. It features an aluminum conductor (AL) for lightweight and cost-effective performance, cross-linked polyethylene (XLPE) insulation for excellent thermal and electrical properties, steel tape armoring (STA) for enhanced mechanical protection, and a durable polyvinyl chloride (PVC) outer sheath for resistance against environmental factors.

Send Email Get Best Price
  • Details

0.6/1kV AL/XLPE/STA/PVC Cable Introduction

Conductor: Aluminum conductor

Insulation:Cross-linked polyethylene XLPE

Filler: Non-hygroscopic material

Binder tape: Non-hygroscopic material

Inner sheath: Polyvinyl chloride PVC

Armour: galvanized steel tape

Outer sheath: Polyvinyl chloride PVC

Application

These cables are suitable for use indoors and outdoors, in cable ducts, underground, in power switch stations, local distribution stations, industrial plants and other places where there is no danger of mechanical damage.

Single cores(STA armoured)

Nominal cross sectional area Insulation thickness Non-magnetic steel tape thickness Sheath thickness Approximate outer diameter Approx. Max.D.C resistance of conductor（20℃） Current carrying capacity
weight
mm2 mm mm mm mm kg/km Ω/km In Air(A) In Ground(A)
1X10 0.7 0.2 1.8 11.8 206 3.08 58 47
1X16 0.7 0.2 1.8 12.9 247 1.91 75 62
1X25 0.9 0.2 1.8 14.6 310 1.2 100 78
1X35 0.9 0.2 1.8 15.2 352 0.868 120 94
1X50 1 0.2 1.8 16.7 423 0.641 145 110
1X70 1.1 0.2 1.8 18.5 523 0.443 190 135
1X95 1.1 0.2 1.8 20.1 629 0.32 235 160
1X120 1.2 0.2 1.8 21.7 738 0.253 270 185
1X150 1.4 0.2 1.8 23.7 877 0.206 310 205
1X185 1.6 0.2 1.8 25.7 1031 0.164 355 235
1X240 1.7 0.2 1.8 28 1254 0.125 - -
1X300 1.8 0.2 1.9 31 1495 0.1 - -
1X400 2 0.2 2 35 1904 0.0778 - -

Two cores(STA armoured)

Nominal cross sectional area Insulation thickness Non-magnetic steel tape thickness  Sheath thickness Approximate outer diameter Approx. Max.D.C resistance of conductor（20℃） Current carrying capacity
weight
mm2 mm mm mm mm kg/km Ω/km In Air(A) In Ground(A)
2X2.5 0.7 0.2 1.8 13.4 236 12.1 - 23
2X4 0.7 0.2 1.8 14.3 269 7.41 - 30
2X6 0.7 0.2 1.8 15.3 307 4.61 - 38
2X10 0.7 0.2 1.8 17.8 397 3.08 50 47
2X16 0.7 0.2 1.8 20 493 1.91 64 62
2X25 0.9 0.2 1.8 23.3 643 1.2 86 78
2X35 0.9 0.2 1.8 24.6 738 0.868 105 94
2X50 1 0.2 1.8 27.2 896 0.641 125 110
2X70 1.1 0.2 1.9 31.4 1164 0.443 165 135
2X95 1.1 0.2 2 35.5 1480 0.32 200 160
2X120 1.2 0.5 2.2 40.2 2164 0.253 235 185
2X150 1.4 0.5 2.3 44.2 2572 0.206 270 205
2X185 1.6 0.5 2.5 48.9 3089 0.164 310 235

Three cores(STA armoured)


Nominal cross sectional area Insulation thickness Non-magnetic steel tape thickness  Sheath thickness Approximate outer diameter Approx. Max.D.C resistance of conductor（20℃） Current carrying capacity
weight
mm2 mm mm mm mm kg/km Ω/km In Air(A) In Ground(A)
3X2.5 0.7 0.2 1.8 13.9 257 12.1 - 23
3X4 0.7 0.2 1.8 14.8 296 7.41 - 30
3X6 0.7 0.2 1.8 16 342 4.61 - 38
3X10 0.7 0.2 1.8 18.6 447 3.08 50 47
3X16 0.9 0.2 1.8 21 563 1.91 64 62
3X25 0.9 0.2 1.8 24.6 744 1.2 86 78
3X35 0.9 0.2 1.8 26 869 0.868 105 94
3X50 1 0.2 1.9 28.9 1074 0.641 125 110
3X70 1.1 0.2 2 33.9 1443 0.443 165 135
3X95 1.1 0.5 2.2 39 2183 0.32 200 160
3X120 1.2 0.5 2.3 42.7 2593 0.253 235 185
3X150 1.4 0.5 2.4 47.5 3155 0.206 270 205
3X185 1.6 0.5 2.6 52.1 3743 0.164 310 235
3X240 1.7 0.5 2.8 58.3 4641 0.125 365 260
3X300 1.8 0.5 2.9 63.6 5508 0.1 420 290

Four cores(STA armoured)


Nominal cross sectional area Insulation thickness Non-magnetic steel tape thickness  Sheath thickness Approximate outer diameter Approx. Max.D.C resistance of conductor（20℃） Current carrying capacity
weight
mm2 mm mm mm mm kg/km Ω/km In Air(A) In Ground(A)
3X2.5 0.7 0.2 1.8 13.9 257 12.1 - 23
3X4 0.7 0.2 1.8 14.8 296 7.41 - 30
3X6 0.7 0.2 1.8 16 342 4.61 - 38
3X10 0.7 0.2 1.8 18.6 447 3.08 50 47
3X16 0.9 0.2 1.8 21 563 1.91 64 62
3X25 0.9 0.2 1.8 24.6 744 1.2 86 78
3X35 0.9 0.2 1.8 26 869 0.868 105 94
3X50 1 0.2 1.9 28.9 1074 0.641 125 110
3X70 1.1 0.2 2 33.9 1443 0.443 165 135
3X95 1.1 0.5 2.2 39 2183 0.32 200 160
3X120 1.2 0.5 2.3 42.7 2593 0.253 235 185
3X150 1.4 0.5 2.4 47.5 3155 0.206 270 205
3X185 1.6 0.5 2.6 52.1 3743 0.164 310 235
3X240 1.7 0.5 2.8 58.3 4641 0.125 365 260
3X300 1.8 0.5 2.9 63.6 5508 0.1 420 290

Five cores(STA armoured)


Nominal cross sectional area Insulation thickness Non-magnetic steel tape thickness  Sheath thickness Approximate outer diameter Approx. Max.D.C resistance of conductor（20℃） Current carrying capacity
weight
mm2 mm mm mm mm kg/km Ω/km In Air(A) In Ground(A)
5X2.5 0.7 0.2 1.8 15.6 321 12.1 - 23
5X4 0.7 0.2 1.8 16.8 376 7.41 - 30
5X6 0.7 0.2 1.8 18.2 443 4.61 - 38
5X10 0.7 0.2 1.8 21.6 592 3.08 50 47
5X16 0.7 0.2 1.8 24.6 763 1.91 64 62
5X25 0.9 0.2 1.8 29 1029 1.2 86 78
5X35 0.9 0.2 1.9 31 1236 0.868 105 94
5X50 1 0.2 2.1 35.7 1616 0.641 125 110
5X70 1.1 0.5 2.3 42.4 2528 0.443 165 135
5X95 1.1 0.5 2.4 47.2 3172 0.32 200 160
5X120 1.2 0.5 2.6 51.8 3801 0.253 235 185
5X150 1.4 0.5 2.7 57.6 4604 0.206 270 205
5X185 1.6 0.5 2.9 63.8 5574 0.164 310 235
5X240 1.7 0.5 3.2 70.7 6859 0.125 365 260
5X300 1.8 0.5 3.4 78 8305 0.1 420 290
